- Powerful, stable, durable, and reliable
- Easy and fast starting, smooth operation, and low vibration.
- Advanced design combustion chamber provides exceptional fuel efficiency and consistent power.
- Heavy duty frame, the unique design of anti-vibration, and low running temperature prolong the generator’s life.
| Model No. | HN1500 | HN2500 | HN3000 | HN3800 | HN4000 | |
|---|---|---|---|---|---|---|
| Engine | Model | HN156FB | HN68FB | HN168FB | HN170F | HN170F |
| Type | Single cylinder,4-stroke,air-cooled | |||||
| Bore x Stroke | 56x40mm | 70x55mm | 70x55mm | 70x55mm | 70x55mm | |
| Displacement | 98cm³ | 212cm³ | 212cm³ | 212cm³ | 212cm³ | |
| Max.output power | 3.5/3600 Hp/rpm | 7.0/3600 Hp/rpm | 7.0/3600 Hp/rpm | 7.0/3600 Hp/rpm | 7.0/3600 Hp/rpm | |
| gnition system | TCL | |||||
| Starting system | Recoil/Electric | |||||
| Fuel tank capacity | 8 liters | 15 liters | 15 liters | 15 liters | 15 liters | |
| Continuous operating time | 11 hours | 10 hours | 10 hours | 10 hours | 10 hours | |
| Oil capacity | 0.35 liters | 0.6 liters | 0.6 liters | 0.6 liters | 0.6 liters | |
| Generator | Rated voltage | 110/220V | 110/220V | 110/220V | 110/220V | 110/220V |
| Rated frequency | 60/50Hz | 60/50Hz | 60/50Hz | 60/50Hz | 60/50Hz | |
| Rated output | 1000W | 2000W | 2300W | 2500W | 2800W | |
| Max.output power | 1100W | 2200W | 2500W | 2800W | 3000W | |
| Packing | N.W | 30Kgs | 39Kgs | 41Kgs | 42Kgs | 44Kgs |
| G.W | 31Kgs | 40Kgs | 42Kgs | 43Kgs | 45Kgs | |
| Carton size | 50x39x43cm | 61x45x47cm | 61x45x47cm | 61x45x47cm | 61x45x47cm | |
| Container Loading | 20 | 330pcs | 240pcs | 240pcs | 240pcs | 240pcs |
| 40 HQ | 852pcs | 490pcs | 490pcs | 490pcs | 490pcs | |
| Model No. | HN4800 | HN6500 | HN8000 | HN9500 | HN110000 | ||
|---|---|---|---|---|---|---|---|
| Engine | Model | HN170FP | HN190F | HN190F | HN192FP | HN192FP | |
| Type | Single cylinder,4-stroke,air-cooled | ||||||
| Bore x Stroke | 70x58mm | 90x66mm | 90x66mm | 92x69mm | 92x69mm | ||
| Displacement | 225cm³ | 420cm³ | 420cm³ | 460cm³ | 460cm³ | ||
| Max.output power | 7.5/3600 Hp/rpm | 15.0/3600Hp/rpm | 15.0/3600Hp/rpm | 19.0/3600Hp/rpm | 19.0/3600Hp/rpm | ||
| gnition system | TCL | ||||||
| Starting system | Recoil/Electric | ||||||
| Fuel tank capacity | 15 liters | 25 liters | 25 liters | 25 liters | 25 liters | ||
| Continuous operating time | 10 hours | 8 hours | 8 hours | 8 hours | 8 hours | ||
| Oil capacity | 0.6 liters | 1.1 liters | 1.1 liters | 1.1 liters | 1.1 liters | ||
| Generator | Rated voltage | 110/220V | 220/380V | 220/380V | 220/380V | 220/380V | |
| Rated frequency | 60/50Hz | 60/50Hz | 60/50Hz | 60/50Hz | 60/50Hz | ||
| Rated output | 3300W | 5000W | 6000W | 7500W | 8000W | ||
| Max.output power | 3500W | 5500W | 6500W | 8000W | 8500W | ||
| Packing | N.W. | 45Kgs | 76Kgs | 78Kgs | 81Kgs | 83Kgs | |
| G.W | 46Kgs | 77Kgs | 79Kgs | 82Kgs | 84Kgs | ||
| Carton size | 61x45x47cm | 70x54x54cm | 70x54x54cm | 70x54x54cm | 70x54x54cm | ||
| Container Loading | 20 | 240pcs | 128pcs | 128pcs | 128pcs | 128pcs | |
| 40 HQ | 490pcs | 272pcs | 272pcs | 272pcs | 272pcs | ||
