- Powerful, stable, durable, and reliable.
- Easy and fast starting, smooth operation, and low vibration.
- Advanced design combustion chamber provides exceptional fuel efficiency and consistent power.
- Low running temperature prolongs the generator’s life.
- Overhead valve design[OHV]
- Easy and fast starting, smooth operation, and low vibration
- Advanced design combustion chamber provides exceptional fuel efficiency and consistent power
- Strong power, durable and reliable
- Unique design of anti-vibration and low running temperature prolongs the engine life
- Different types of P.T.0 shafts meet various demands
| Mode | 152F/P | 154F/P | 168FA/P | 168FB/P | 170F/P | 173F/P | 177F/P | 182FA/P | 188F/P | 190F/P |
|---|---|---|---|---|---|---|---|---|---|---|
| Form | Single cylinder,four stroke,forced air cooling | |||||||||
| Lgnition mode | Contactless transistor electronic ignition | |||||||||
| Starting mode | Recovery manual start | |||||||||
| Fuel consumpfion (g/kW h) | ≤450 | ≤420 | ≤395 | ≤395 | ≤374 | ≤374 | ≤374 | ≤374 | ≤374 | ≤374 |
| Bore/stroke (mm) | 52x46 | 54x38 | 68x45 | 68x45 | 70x45 | 73x58 | 77x58 | 82x64 | 88x64 | 90x66 |
| Piston displacement (ML) | 98 | 87 | 163 | @ | 215 | 242 | 270 | 338 | 389 | 420 |
| Maximum power /speed Kw/rpm | 1.15/3600 | 1.15/3600 | 3.2/3600 | 3.8/3600 | 4.0/3600 | 4.2/3600 | 4.6/3600 | 6.1/3600 | 7.2/3600 | 8.1/3600 |
| Maximum torque (N.m/rpm) | 2.5/2600 | 3.0/2600 | 8.8/2600 | 10.2/2600 | 12/2600 | 13/2600 | 14/2600 | 19/2500 | 21/2500 | 23/2500 |
| Net weight (kg) | 8.8 | 10 | 18 | @ | 18 | 25 | 25 | 31 | 31 | 32 |
| Boundary dimension [mm](LxWxH) | 280x270x345 | 280x270x345 | 350x315x335 | 350x315x335 | 350x315x335 | 495x430x505 | 495x430x505 | 495x430x505 | 495x430x505 | 495x430x505 |
