Low running noise
A high high-efficiency combustion system ensures complete combustion, A large silencer dampens exhaust noise, and engine sounds are contained by a double wall structure and liner absorber.
Advanced alternator winding
Waveform distortion is kept at a minimum level with a stable output. The winding design protects the generator from short circuits and provides a stable output while running inductive loads.
Low oil alarm system
Before the oil level drops to a dangerous level, the generator will stop automatically. it can only be restarted after the proper oil level is restored.
Application of new AVR
The automatic voltage regulator (AVR) not only can smooth the output but also provides protection against overload, avoiding expensive damage.
Strong power
All generators are powered by four-stroke diesel engines
| Model | HN4500T | HN6500T | HN8500T | HN6500X3/E3 | HN8500X3/E3 |
|---|---|---|---|---|---|
| Rated Frequency | 50 60 | 50 60 | 50 60 | 50 60 | 50 60 |
| Rated Output | 2.8 6.3 | 4.5 5 | 6 7 | 5.5 6.3 | 7.5 8 |
| Maximun Output Power | 3.2 3.8 | 5 5.5 | 6.5 7.5 | 6 7 | 8 8.8 |
| The Rated Voltage | 220/380V | 220/380V | 220/380V | 220/380V | 220/380V |
| Rated Currentel | 24.3/12.227.5/13.5 | 39.1/19.641.7/20.8 | 52/2654/27 | 7.9 8.7 | 10.8 11.5 |
| Rated Speed | 3000 3600 | 3000 3600 | 3000 3600 | 3000 3600 | 3000 3600 |
| The Power Factor | 1.0 | 1.0 | 1.0 | 0.8 (lag) | 0.8 (lag) |
| Engine Model | HN178FGET | HN186FAGET | HN192FAG | HN186FAG | HN192FAG |
| Cylinder Structure Type | Vertical single cylinder,four stroke,air-cooled,direct injection | ||||
| The cylinder diameter X Trip | 78x62 | 86x72 | 92x75 | 86x72 | 92x75 |
| The Total Displacement | 296 | 418 | 499 | 418 | 499 |
| Compression Ratio | 20:1 | 19:1 | 19:1 | 19:1 | 19:1 |
| Rated Power | 3.68 4 | 5.7 6.3 | 7.5 8.2 | 5.7 6.3 | 7.5 8.2 |
| Lubricating Oil Type | Above CD level or SAE 10W-30,15aw-40 | ||||
| Lubricating Oil Capacity | 1.1 | 1.65 | 1.65 | 1.65 | 1.65 |
| Fuel Type | Diesel:0×3(summer)-10×3(winter)-35×3(severe cold) | ||||
| Unit fuel Consumption Rate | ≤370 | ≤360 | ≤360 | ≤360 | ≤360 |
| Noise 7m | 72 | 72 | 72 | 79 | 72 |
| Unit fuel Tank Capacity | 15 | 15 | 15 | 13.5 | 13.5 |
| Unit Dimension | 830x532x740 | 912x532x740 | 930x535x742 | 720x492x655 | 740x515x640 |
| The Unit Net Weight | 140 | 158 | 170 | X3:95 E3:100 | X:100 E:160 |
